• Connectivity: E-stop, USB update, DRM, Counter
• Topology: Transformerless
• Cooling system: Forced convection
• Protection class: 1 / AC: III; DC: ll
• Installation height (max): 3000 m
• Efficiency: 98.6%
• Built-in display: LCD
• Product colour: White
• Electromagnetic compatibility: IEC 61000-6-1 /IEC 61000-6-2 /IEC 61000-6-3 /IEC61000-4-2/3/4/5/6/8
• Safety: IEC 62109-1/2
• Power supply type: Indoor/outdoor
• Power current type: DC-to-AC
• Purpose: Solar panel
• Number of phases: 3
• International Protection (IP) code: IP65

• Nominal AC power: 25000 W
• Rated mains frequency (Hz): 50/60, ±5
• Maximum AC current: 39.9 A
• Nominal operating voltage: 600 V
• Strings for MPP tracker: 2+2
• Start-up voltage: 140 V
• Maximum input voltage: 1100 V
• Max. short circuit current of the module field: 36.4 / 36.4 A
• MPPT voltage range: 140 - 1000 V
• Number of MPP trackers: 2
• Apparent power: 27500 VA
• Nominal AC current: 36.2 A
• Input current: 28 / 28 A
• Output voltage: 3/N/PE, 220V/380V, 230V/400V 240V/415V
• Maximum input power: 37500 W

• Temperature protection: Y
• Monitoring of leakage current: Y
• Monitoring of isolation: Y
• Overvoltage protection of AC output: Y
• Island mode protection: Y
• Overvoltage protection: Y
• Polarity reverse circuit protection: Y
• Short circuit protection: Yes
• Overcurrent protection: Y

• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 0 - 100%
• Operating temperature (T-T): -25 - 60 °C

• Weight: 20 kg
• Height: 370 mm
• Depth: 183.5 mm
• Width: 480 mm
